Valkey Helm: The new way to deploy Valkey on Kubernetes

2026-01-06 · Silvio Gissi, Mahesh Cherukumilli

Last year, Bitnami changed how it publishes and supports many container images and Helm charts (see charts issue #35164, charts issue #36215, and the Bitnami Secure Images announcement). Some images move behind new terms, and older tags may not be available as before.

If your pipelines pull Bitnami charts or images during deploys, you may experience significant operational issues: rollouts can fail with ImagePullBackOff or auth/404 errors, clusters can drift when staging keeps old cached images while production can't pull or resolve a different tag, and "invisible" upgrades can occur when a moved tag points to a new digest. During incidents, rollbacks may slow down or fail entirely because the old image isn't fetchable.

To reduce the impact on Valkey deployments, the community created an official, project-maintained Helm chart (request: issue #2371, chart: valkey-helm). With the official chart, you can pin chart and image versions, keep values.yaml in code, and upgrade on your schedule without depending on vendor policy changes.

Why a Valkey maintained chart helps

With the official chart, you control exactly which versions you deploy, without third-party vendor policies forcing unexpected changes. Pin a chart release from the Valkey repo (for example --version 0.9.2 from https://github.com/valkey-io/valkey-helm) and lock the Valkey image tag in your values.yaml. Because the chart follows Valkey releases and docs, you can bump versions in a pull request, test in staging, then promote the same versions to production.

Capabilities in the Valkey Helm Chart

The official Valkey Helm chart supports the following:

Standalone instance - Deploy a single Valkey instance with or without data persistence, perfect for simple caching layers and development environments.
Replicated read-heavy workloads - Use a primary-replica topology with separate read and read-write endpoints, distributing read traffic across all replica instances while routing writes to the primary node.
ACL-based authentication - Enable authentication using Access Control Lists for fine-grained user permissions and password-based authentication.
TLS encryption - Enable TLS for encrypted client-server and replica-primary communication, protecting data in transit.
Metrics - Collect Valkey metrics by enabling the Prometheus exporter.

For details on how to configure these capabilities and customize your deployment, see the chart README.

Migrating from Bitnami to the Official Valkey Chart

Because of differences in how the two charts structure resources, labels, and StatefulSets, you can't upgrade in-place from Bitnami. The charts use incompatible naming conventions and resource management approaches. Instead, deploy the official Valkey chart alongside your existing Bitnami installation and migrate the data. Plan for a brief maintenance window to ensure all writes are fully replicated before switching your applications to the new endpoints.

Before You Migrate

Review the official chart documentation to understand configuration options and match your current Bitnami settings. Bitnami's default configuration deploys one primary with three replicas, protected by a randomly-generated password and without TLS. The migration steps below will configure the official chart the same way — adjust the chart parameters to match your current deployment.

Ensure you are using Bitnami Valkey chart version 2.0.0 or higher. That release updated service names and labels from master to primary for consistency with current terminology, and the migration steps below assumes that naming convention.

The following commands should be executed from a Bash shell. You'll need kubectl configured to access your Kubernetes cluster, helm to install the new chart, and the standard utilities grep and base64.

Step 1: Find existing pods, services and namespace

# List all pods in all namespaces with app name 'valkey'
kubectl get pods --all-namespaces -l app.kubernetes.io/name=valkey -o custom-columns=Pod:.metadata.name,Namespace:.metadata.namespace,Instance:.metadata.labels.app\\.kubernetes\\.io\\/instance
# * Sample Output *
# Pod                                 Namespace   Instance
# valkey-bitnami-primary-0            apps-test   valkey-bitnami
# valkey-bitnami-replicas-0           apps-test   valkey-bitnami
# valkey-bitnami-replicas-1           apps-test   valkey-bitnami
# valkey-bitnami-replicas-2           apps-test   valkey-bitnami

Replace values below with the namespace and instance above:

export NAMESPACE="apps-test"
export INSTANCE="valkey-bitnami"

Save current environment details to be used for replication:

# Identify the name of the current primary service
export SVCPRIMARY=$(kubectl get service -n $NAMESPACE -l app.kubernetes.io/instance=$INSTANCE,app.kubernetes.io/name=valkey,app.kubernetes.io/component=primary -o jsonpath='{.items[0].metadata.name}')

# Fetch the default user password
export PASS=$(kubectl get secret -n apps-test -l app.kubernetes.io/name=valkey,app.kubernetes.io/instance=valkey-bitnami -o jsonpath='{.items[0].data.valkey-password}' |  base64 -d)

Step 2: Deploy a new Valkey server

Choose an instance name for the new deployment. It must be different from the current instance to avoid overwriting resources.

export NEWINSTANCE="valkey"

Add the official Helm chart repository:

helm repo add valkey https://valkey.io/valkey-helm/
helm repo update

Create a values.yaml file that matches your current deployment, for details on the configuration options, check the chart README and values.yaml. The script below will generate a file that matches the default Bitnami Valkey configuration:

Note: The example below provides the password as plain-text for simplicity. In production, store the password in a Kubernetes Secret and reference it using the auth.usersExistingSecret setting.

cat << EOF > values.yaml
auth:
  enabled: true
  aclUsers:
    default:
      password: "$PASS"
      permissions: "~* &* +@all"

replica:
  enabled: true
  replicas: 3
  persistence:
    size: 8Gi

valkeyConfig: |
  appendonly yes
EOF

Install the new Valkey instance:

helm install -n $NAMESPACE $NEWINSTANCE valkey/valkey -f values.yaml

Check it is running as expected:

# List new pods and ensure they are in 'Running' state
kubectl get pods -n $NAMESPACE -l app.kubernetes.io/instance=$NEWINSTANCE
# * Sample Output *
# NAME       READY   STATUS    RESTARTS   AGE
# valkey-0   1/1     Running   0          2m33s
# valkey-1   1/1     Running   0          2m16s
# valkey-2   1/1     Running   0          2m4s
# valkey-3   1/1     Running   0          103s

# Check that server is responding to CLI commands
kubectl exec -n $NAMESPACE $NEWINSTANCE-0 -c valkey -- valkey-cli -a $PASS --no-auth-warning ping
# * Sample Output *
# PONG

# Check that the current instance is reachable from the new instance
kubectl exec -n $NAMESPACE $NEWINSTANCE-0 -c valkey -- valkey-cli -a $PASS -h $SVCPRIMARY --no-auth-warning ping
# * Sample Output *
# PONG

Create shell aliases to call the Valkey CLI on the new and current instances:

alias new-valkey-cli="kubectl exec -n $NAMESPACE $NEWINSTANCE-0 -c valkey -- valkey-cli -a $PASS --no-auth-warning"
alias current-valkey-cli="kubectl exec -n $NAMESPACE $NEWINSTANCE-0 -c valkey -- valkey-cli -a $PASS -h $SVCPRIMARY --no-auth-warning"

Step 3: Enable replication

Replicate data from current instance and ensure it is replicating:

# Configure password to connect to existing Valkey instance
new-valkey-cli config set primaryauth $PASS
# * Sample Output *
# OK

# Configure new instance to replicate data from the current instance
new-valkey-cli replicaof $SVCPRIMARY 6379
# * Sample Output *
# OK

# Check status of replication, it should return a 'slave' role and master_link_status as 'up'
new-valkey-cli info replication | grep '^\(role\|master_host\|master_link_status\)'
# * Sample Output *
# role:slave
# master_host:valkey-bitnami-primary
# master_link_status:up

Step 4: Enter maintenance window

Pause all clients connecting to the Valkey server deployed using Bitnami's chart. The failover process will pause client writes, ensure changes are replicated, and promote the new instance to primary:

# Retrieve the new instance Pod IP
export PODPRIMARY=$(kubectl get pod -n $NAMESPACE $NEWINSTANCE-0 -o jsonpath='{.status.podIP'})
# Initiate failover
current-valkey-cli failover to $PODPRIMARY 6379
# * Sample Output *
# OK

# Check that instance role is 'master'
new-valkey-cli info | grep '^role:'
# * Sample Output *
# role:master

Step 5: Switch clients to new endpoints

Update all clients to use the new Valkey read-write and read-only endpoints which are exposed as services. To list the service endpoints:

echo "Read-Write (primary): $NEWINSTANCE.$NAMESPACE.svc.cluster.local"
echo "Read-only (all instances): $NEWINSTANCE-read.$NAMESPACE.svc.cluster.local"

What's next for Valkey Helm?

The chart milestones outlines the planned improvements for the official Valkey Helm chart, which is being actively developed in the open at the valkey-io/valkey-helm repository. High-availability via Sentinel for automated failover is the next upcoming feature #22, alongside more control over data persistence #88, followed by Cluster support #18.

Get started today

If you currently rely on Bitnami, test this chart in a dev cluster and try your normal workflows. The official Valkey Helm chart provides a stable, community-maintained path forward that puts you in control of your deployment lifecycle.

If something is missing or you encounter issues, the Valkey community is here to help. Open an issue at valkey-io/valkey-helm or reach out on the #valkey-helm Slack channel. Your feedback helps ensure the chart grows in the right direction for the entire community.
